E 385 - 16

Name: E 385 - 16
Brand: SHREE KAILAJI ALLOYS PVT. LTD.
Price: 200.0 INR
Availability: InStock

Price 200.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

E 385 - 16 Specification

Usage
WELDING

Material
STAINLESS STEEL

Diameter
2.5 mm, 3.15 mm, 4.0 mm, 5.0 mm

Length
350 mm, 450 mm

Opening Pattern
Standard

Voltage
60 V Max (Open Circuit)

Welding Current
60-120 A (Depending on Diameter)

Color
SILVER

Working Temperature
Up to 300C

Type of Coating
Rutile

Storage Conditions
Dry and moisture free area

Conforming Standard
AWS A5.4 E385-16

Tensile Strength
580 MPa (Min)

Packaging
5 kg, 20 kg box

Application
Welding of 904L and similar grade stainless steel

Current Type
AC/DC

E 385 - 16 Trade Information

Minimum Order Quantity
100 Pieces

Delivery Time
3 Days

Packaging Details
BOX

Main Domestic Market
All India

About E 385 - 16

AWS classification for a rutile-coated, basic electrode used for welding high-alloy austenitic stainless steels like Type 904L, depositing a low-carbon, molybdenum-copper alloy that offers excellent corrosion resistance in harsh, non-oxidizing environments such as sulfuric and phosphoric acid, making it ideal for chemical processing equipment. The electrode produces a fully austenitic, X-ray quality weld metal with low carbon, silicon, and phosphorus for crack resistance, providing superior pitting and crevice corrosion resistance in chloride-bearing media.

Key Characteristics:

Type: Covered Electrode (Stick Welding).
Coating: Rutile based.
Deposit: Fully austenitic, low carbon, high alloy (Cr-Ni-Mo-Cu).
Corrosion Resistance: Excellent against sulfuric acid, phosphoric acid, chlorides, and other reducing media.
Applications: Welding 904L, 317L, HV-9, Sandvik 2RK65, and similar alloys for tanks, vessels, and piping in chemical plants.
Weld Quality: Smooth beads, easy slag removal, low spatter, and radiographic quality.

In simpler terms, it's a specialized welding rod for tough chemical applications where standard stainless steels fail, providing a highly corrosion-resistant weld.

Specially Formulated for Superior Stainless Steel Welding

E 385-16 electrodes are crafted to provide excellent weldability for 904L and comparable stainless steel grades. The rutile coating offers smooth arc stability and spatter control, resulting in clean, strong welds with a silver finish. Each electrode meets the stringent AWS A5.4 E385-16 standard, ensuring dependability in demanding operations.

Versatile Options for Various Welding Needs

Choose from a selection of electrode diameters (2.5 mm to 5.0 mm) and lengths (350 mm and 450 mm), making E 385-16 suitable for both intricate and heavy-duty work. The flexible current compatibility (AC/DC) and a maximum open circuit voltage of 60 V provide adaptability across diverse welding setups, promoting efficiency and consistent results.

Reliable Performance and Easy Storage

With a minimum tensile strength of 580 MPa and recommended working temperature up to 300C, E 385-16 electrodes deliver resilience and durability. Convenient packaging in 5 kg and 20 kg boxes enhances storage and transport. For best performance, keep electrodes in a dry, moisture-free area to maintain integrity and prevent degradation.

FAQ's of E 385 - 16:

Q: How should E 385-16 electrodes be stored for maximum performance?

A: E 385-16 electrodes must be kept in a dry, moisture-free area to prevent deterioration of their rutile coating and ensure reliable weld quality. Proper storage maintains their welding effectiveness and prevents absorption of humidity that could compromise welds.

Q: What types of stainless steel can E 385-16 be used with?

A: E 385-16 is specially designed for welding 904L stainless steel and other grades with similar chemical compositions, providing exceptional strength and corrosion resistance in the finished joint.

Q: When is it best to use E 385-16 electrodes?

A: Use E 385-16 electrodes when working on projects that require high corrosion resistance and strong welds, particularly with 904L and similar stainless steel materials, in industries such as chemical, pharmaceutical, or food processing.

Q: Where can I purchase E 385-16 electrodes in India?

A: You can obtain E 385-16 electrodes from authorized importers, manufacturers, suppliers, and traders across India, often available in standard 5 kg or 20 kg packaging.

Q: What is the recommended welding current and voltage for E 385-16 electrodes?

A: Depending on the diameter, use a welding current ranging from 60 to 120 A, with a maximum open circuit voltage of 60 V. This range ensures optimal arc stability and weld quality.

Q: How does the rutile coating benefit the welding process with E 385-16?

A: The rutile coating provides smooth arc initiation, excellent slag removal, and reduced spatter during welding. These advantages result in cleaner, aesthetically pleasing welds and enhanced productivity.

Q: What are the main benefits of using E 385-16 electrodes?

A: E 385-16 offers high tensile strength, adaptability to both AC and DC currents, and reliable performance at working temperatures up to 300C. Its compatibility with various lengths and diameters, along with convenient packaging, makes it suitable for diverse welding requirements.
